Robot Shared Autonomy via Immersive Interfaces
Under Communication Delays and Bandwidth Constraints

PhD (September 2023 - today).

I am developing a supervisory control-based robot teleoperation system for remote manipulation in space. The standard approach of direct teleoperation of the robot with shared control approaches (i.e. adjustment and correction of continuous user input to some extent) is unsuitable in scenarios where the communication medium between the local (operator's) and remote (robot's) environments is challenged by long delays and limited communication windows or bandwidth. My system's architecture involves immersing the operator in Augmented Reality where the operator is able to see a visualization of the robot's environment, monitor/supervise task execution by setting high-level goals to the robot, and correcting any errors reported back from the robot during execution.

There is an on-going collaboration with the SpaceR Space Robotics Research Group at the University of Luxembourg to test my system in a space robotics use case, where the robot has to assemble a modular solar panel structure in space. The proof of concept was presented at the iSpaRo (International Conference on Space Robotics) in Luxembourg in June 2024. The system has the potential to be generalized such that it can be used in nuclear and underwater robotics scenarios.

Visit my profile on the official Cardiff University staff website.

Proof of concept (iSpaRo'24 conference workshop paper)

The proof of concept demonstrated the feasibility of my proposed and it served as a validation step in my research. Nasa, AirBus, and DLR (German Aerospace Center) clarified that autonomy will be a core feature of any in-space robotics system in the future.

Setting high level goals (green placeholders) to the Franka Emika manipulator robot virtual surrogate for a structure assembly task.

1^st Iteration of proposed supervisory control scheme

The development of the proof of concept and the feedback received led to the first iteration of my proposed solution featuring high-level goal scene specification, and error visualization and correction in Augmented Reality. Futher, the original system has been completely re-written to support ROS2 and now uses Behavior Trees as the underlying control architecture. Behavior Trees are dynamically generated at runtime, based on the goal scene specification, and can also be modified (automatically) at runtime depending on user feedback in case of any errors during execution.

Side products from the development of the system

• ROS2 migration
• The original system now uses Gazebo Ignition Fortress (recommended simulation software by Franka Emika robot manufacturer) and MoveIt! 2. The visualization software developed in Unity has also been updated to support these changes.
• Gazebo ROS Link Attacher plugin
• I developed a link attacher plugin, used in simulated pick and place manipulation tasks, that is compatible with Gazebo Ignition and works with ROS2. Even though Gazebo Ignition has improved friction physics relative to Gazebo classic, such a plugin is vital for the development and testing of simulations where the focus of the research is not control theory. This is now being used privately in the Cardiff University Computational Robotics Group.

BSc graduation project (7 February 2023 - 22 March 2023)

A1

Unitree A1 quadruped robot

The goal of this project is to investigate how Augmented Reality (AR) can be used to facilitate the interaction and control of a robot; the Unitree A1 quadruped robot in particular. This project explores the different modalities that could be used to give navigation commands to a robot via an AR Head-Mounted Display (HMD), and investigates how intuitive AR is for understanding robot-generated data by displaying holographic content that is superimposed on the real environment of the person who controls the robot.

The system comprises two main components:

AR interface

• Interface to set/unset/publish/cancel high level goals to the robot using eye, head, or hand tracking
• Visualizes task execution status
• Visualizes the state of the robot
• Visualizes 3D map of the robot's surroundings (real or simulated) - The user can move around and explore the reconstructed environment in the real world, as if the virtual and real environments were one
• Visualizes planned robot trajectory
• Developed in Unity for the Microsoft HoloLens 2 (HL2)

Robot Operating System (ROS)

• Middleware used to interface with the robot and develop software for it at various levels of abstraction (Python/C++)
• Gazebo simulation of the robot (replaceable by real robot)
• Action server that listens for and executes navigation goals sent from the AR application
• Simultaneous Localization and Mapping (SLAM) for dynamic obstacle avoidance
• 3D map reconstruction of robot's surroundings using Octomap

Microsoft HoloLens 2 headset

There are four modalities that enable the user to control the robot:

• Point & Commit: User aims with their hand and does a grab gesture to set a goal (demonstrated in video)
• Head Gaze: User turns their head and keeps still for two seconds to lock in a goal
• Eye Gaze: User looks around with their eyes and focuses at a point for two seconds to lock in a goal
• Teleoperation (Hand Tracking): User turns palm face-up to take manual control of the robot and raises ring, middle, or index finger to move the robot left, forward, or right respectively.

The user uses a near-interaction menu to control which modalities are active at any time, or to publish, cancel, or unset a goal. Once the user has used any of the modalities to set a goal, in the real environment, they can then publish it to the robot which will move to these coordinates in virtual space. Due to the implementation of the system, the virtual surrogate robot can be swapped with the real one for real life applications (i.e. search and rescue missions in charred ruins, or exploration of radioactive areas etc.).

Technologies involved:

Project: Boost - devStav

[Game Under Development]

Side project to practice game development in Unity with C#.

Self Hosting

This website was developed using the MERN stack in typescript. It is hosted on a Raspberry Pi 4 and uploaded under my stavro.dev domain. Cloudflare Zero Trust tunnels are used such that no open ports in my home network are exposed to the internet. My ioannismarios.com domain currently redirects to stavro.dev.

Kernel Core

Kernel Core is a sample E-Commerce website written in Python using Flask. It was first developed as a project in university Year 1 and has since been refactored to use the NoSQL MongoDB database rather than a relational one. It can be accessed via kc.ioannismarios.com.

Neighbourfy

Neighbourfy is a group project I was a co-developer of in university Year 2. It is a sample gardening tool sharing website. My responsibilities included helping designing and implementing the database, integrating the ArcGIS maps API, implementing the personal profile page, and retouching the aesthetics of the website. It can be accessed via neighbourfy.com.

Computer Vision powered IoT security camera

Concept of a security alarm system that consists of a door-mounted device that detects movement and is disarmed by using hand gestures. An admin control panel where processed data and statistics are displayed is also provided. I was a co-developer of this university Year 2 group project.
